Overview:

Krystal is a renowned exporter, manufacturer, stockist, supplier, and stockholder of high-quality Nickel Alloy Seamless Tubes. These tubes are celebrated for their excellent corrosion resistance, high-temperature strength, and durability, making them ideal for applications in aerospace, chemical processing, power generation, and marine industries. Nickel alloy tubes maintain their mechanical properties across a wide temperature range, ensuring consistent performance in demanding environments. Additionally, they offer superb weldability and ease of fabrication, making them a reliable choice for a variety of critical applications.

Nickel 200 Pipe is made up of a commercially pure grade of nickel. This is a wrought product that has good strength and very high corrosion resistant properties. The material also has very low electrical resistance. Steel India Company is a leading manufacturer and supplier of the Nickel Alloy 200 Pipe products in various dimensions and types. The material is resistant against many agents, especially to hydroxides. The specifications for the Nickel 200 Seamless Pipe are ASTM B161 and B622 with the dimensions varying according to the ASTM, ASME and API standards.

Commercially pure (99.6%) wrought nickel with good mechanical properties and resistance to a range of corrosive media. Good thermal, electrical and magnetostrictive properties. Used for a variety of processing equipment, particularly to maintain product purity in handling foods, synthetic fibers and alkalies.

AVAILABLE TUBE PRODUCT FORMS
Seamless Straight Tube \| Straight Pipe \| U - Tube \| Coiled Tube

TYPICAL MANUFACTURING SPECIFICATIONS
B161	B163
SB161	SB163
Also individual customer specifications.

TYPICAL APPLICATIONS
HEAT EXCHANGERS
WELL HEAD COMPLETION EQUIPMENT
MANDRELS
VALVES

INDUSTRIES PREDOMINANTLY USING THIS GRADE
AEROSPACE
OIL AND GAS
NUCLEAR AND POWER

Technical Specifications

CHEMICAL COMPOSITION (% by weight)
Element	Ni	Cu	S	C	Fe	Si
Min	99	-	-	-	-	-
Max	-	0.25	0.01	0.15	0.40	0.35

PHYSICAL PROPERTIES (Room Temperature)
Melting Range	2615 – 2635	°F	1435 – 1446	°C
Specific Heat	0.109	Btu/lb•°F	456	J/kg•°C
Curie Temperature	680	°F	360	°C
Coefficient of Expansion	7.4	70 – 200°F, 10-6 in/in•°F	13.3	21 – 93°C, µm/m•°C
Thermal Conductivity	487	Btu • in/ft2 •h•°F	70.2	W/m • °C
Electrical Resistivity	58	ohm • circ mil/ft	0.096	µΩ•m
Density	0.321	Ib/in³	8.89	g/cm³
Coefficient of Expansion	Ferromagnetic

MECHANICAL PROPERTIES
Temper	Annealed
Tensile Rm	67	ksi (min)
Tensile Rm	462	MPa (min)
R.p. 0.2% Yield	21.5	ksi (min)
R.p. 0.2% Yield	148	MPa (min)
Elongation (2” or 4D gl)	47	% (min)
