TP 314 • 1.4841

Manufacturer of TP 314 | TP 314 Stainless Steel

Manufacturer of TP 314 | TP 314 Stainless Steel | TP 314 Seamless Tubes | TP 314 Welded Tubes | TP 314 Pipes | TP 314 Tubes Supplier | TP 314 Tubing Manufacturer | TP 314 ERW TUBE | TP 314 WELDED TUBE | 1.4841 Stainless Steel | 1.4841 Seamless Tubes

Overview:

Krystal is a renowned exporter, manufacturer, stockist, supplier, and stockholder of high-quality TP 314 Stainless Steel Tubes and Pipes. These chromium-nickel alloy products are celebrated for their exceptional resistance to oxidation and high-temperature strength, making them ideal for use in extreme conditions, including chemical processing, petrochemical industries, power generation, and high-pressure environments. TP 314 offers excellent weldability, making it suitable for fabrication and forming applications in various industries.

TP 314 (1.4841 / UNS S31400) is a high-chromium, high-nickel alloy designed for high-temperature applications. It maintains excellent resistance to scaling and oxidation at elevated temperatures and provides superior resistance to sulfur compounds and carburizing environments. The alloy’s high nickel content further enhances its resistance to corrosion in aggressive environments, ensuring longevity and durability in harsh conditions.

TP 314 is widely used in applications requiring high strength, oxidation resistance, and durability in extreme temperatures. Typical applications include furnace parts, heat exchangers, flue gas scrubbers, chemical process equipment, combustion chambers, and components in power plants and refineries. Its ability to withstand high temperatures while maintaining structural integrity makes TP 314 the material of choice for demanding industries.

AVAILABLE TUBE PRODUCT FORMS
Straight Tube | Straight Pipe | U - Tube | Coiled Tube
TYPICAL APPLICATIONS
HEAT EXCHANGERS
STEAM GENERATORS
REBOILER TUBES
BRINE HEATERS AND EVAPORATOR BODIES IN SALT PLANT
NUCLEAR CORE COOLING TUBES
SULPHURIC AND HYDROFLURIC ACID ALKYLATION PLANT
CONTROL LINES
TYPICAL MANUFACTURING SPECIFICATIONS
- -
- -
Also individual customer specifications.
INDUSTRIES PREDOMINANTLY USING THIS GRADE
CHEMICAL PROCESSES
OIL AND GAS
NUCLEAR AND POWER

Technical Specifications

CHEMICAL COMPOSITION (% by weight)
Element Min Max
C - 0.20
Mn - 2.00
Si 1.50 2.00
P - 0.045
S 0.015
Cr 24.00 26.00
Ni 19.00 22.00
N - 0.11
PHYSICAL PROPERTIES (Room Temperature)
Specific Heat (0-100°C) 500 J.kg-1.°K-1
Thermal Conductivity 14.9 W.m -1.°K-1
Thermal Expansion 16.0 mm/m/°C
Modulus Elasticity 200 GPa
Electrical Resistivity 70 μOhm-cm
Density 8.0 g/cm³
MECHANICAL PROPERTIES
Temper Annealed
Tensile Rm 80ksi (min)
Tensile Rm 550MPa (min)
R.p. 0.2% Yield 35ksi (min)
R.p. 0.2% Yield 240MPa (min)
